Sinking Ant Towers

Jason Maderer July 11, 2017

If you want to see the Eiffel Tower, you don’t have to go to Paris. Just look down at your feet — but watch your step.

Fire ants use their bodies to construct Eiffel Tower-looking structures when they run into a tall obstruction while looking for food or escaping to new areas. A new study from the Georgia Institute of Technology suggests that they build these structures without a leader or coordinated effort. Each ant wanders around aimlessly, adhering to a certain set of rules, until it unknowingly participates in the construction of a tower several inches tall.

“If you watched ants for 30 seconds, you could have no idea that something miraculous would be created in 20 minutes,” said co-author David Hu, a professor in Georgia Tech’s George W. Woodruff School of Mechanical Engineering. “With no planning, and using trial-and-error, they create a bell-shaped structure that helps them survive."

How Towers Form

How they're built, how they sink, and where ants go.

The tower study is a follow-up to the group’s 2014 ant raft research, which examined how the insects link their bodies in order to build waterproof structures that stay afloat for months. The ants march along until they come to an open space — the edge of the raft — then settle in to become a building block of the raft.

They do the same thing for the towers, searching for an empty spot like a car in a crowded parking lot. Once an individual ant finds one, typically at the top of the tower, she stops and braces for more ants to climb on top and go vertical.

Gifs of ants walking

But vertical is a relative term. The ants don’t position themselves straight up and down like a skyscraper. Instead, the tower gets wider as it grows taller, gradually becoming the same shape as Paris’ iconic landmark. The weight of the tower is supported by a wider cross-section at its base, which allows the ants to better distribute their weight.

“We found that ants can withstand 750 times their body weight without injury, but they seem to be most comfortable supporting three ants on their backs,” said Craig Tovey, a co-author of the study and professor in the Stewart School of Industrial & Systems Engineering. “Any more than three and they’ll simply give up, break their holds and walk away.”

Ant towers and the Eiffel Tower

The weight of towers, both in France and made by ants, is supported by a wider cross-section at the base. This allows an equal distribution of the weight.

Even though the ants evenly distribute their weight as a group, the tower is in constant motion. The column sinks as the insects work, as if the bottom is being melted like butter. The ants slide down, then exit out of tunnels buried in the base. The tower’s movement is similar to a slow-motion chocolate fountain in reverse.

The sinking towers were discovered by accident. The researchers planned to record ants building for two hours, but the camera rolled for three.

“We didn’t expect to see anything interesting in that extra hour, so we sped up the video to 10 times real speed,” said Tovey. “We were amazed at how different the ant movements appeared.”

In real time, they saw ants busily moving on the surface of a tower of apparently stationary ants. At high speed, however, the surface ant movements appeared as a blur and the entire tower slipped downward.

“The tower sinking was too slow to see at real speed,” said Tovey.

The sinking was confirmed by X-ray videography. The researchers fed some of the ants radioactive food, then threw the colony in an X-ray machine across campus in Professor Dan Goldman’s physics lab. Cameras again recorded the critters building a tower. Using time-lapse photography, they watched the radioactive insects walk up the sides, gradually sink to the tower’s depths, leave the pile, then continually repeat the process for hours.

Ant head

An ant head, magnified 10 times.

"Ant towers are like human skin,” said Hu, who is also a faculty member in the School of Biological Sciences. “The tower is constantly rebuilding and replacing its surface.”

The findings, which are now published in the journal Royal Society Open Science, could have implications for modular robots, which currently aren’t very effective at building tall towers.

Tovey, who is also a biologist, has a different reason for studying ant behavior.

“Ninety-nine percent of all the species that have ever lived on Earth are extinct,” Tovey said. “The rest of us have developed very effective techniques to survive. Why wouldn’t we study these processes? Engineers and scientists don’t always know what our findings will lead to, but bioinspired design can be a powerful tool to make our world more efficient.”

The paper, “Fire ants perpetually rebuild sinking towers,” was published on July 11.

The study is supported US Army Research Laboratory and the US Army Research Office Mechanical Sciences Division, Complex Dynamics and Systems Program (grant number W911NF-12-R-0011). It is also supported by the David McKenney Family Professorship at Georgia Tech. Any opinions, findings and conclusions or recommendations expressed in this material are those of the authors and do not necessarily reflect the views of the sponsor.

(Photo credits: Tim Nowack and Candler Hobbs; Video credit: Sulisay Phonekeo)
